Drill - Magnetic, REG CHUCK - 1/2

Milwaukee 4297-1 No. 3 MT Motor for Electromagnetic Drill Press Specifications

General:
- Type: Magnetic drill motor (for use with electromagnetic drill press base)
- Application: Heavy-duty steel drilling, fabrication, production drilling
- Compatibility: Designed for Milwaukee mag drill bases (e.g., 4203)

Motor & Power:
- Motor: 11.5 amp
- Voltage: 120V AC
- Power Source: Corded electric
- Cord Length: 8 ft

Performance:
- Speeds: 2-speed gearbox
  - Low: 250 RPM
  - High: 500 RPM
- Drill Point Pressure: Up to 1,530–1,600 lb
- Torque: High torque (geared low for heavy drilling)

Drilling Capacity:
- Max Drill Capacity: 1-1/4 in (31.75 mm)
- Tap Capacity: Up to 1 in – 14 thread
- Chuck / Taper: No. 3 Morse Taper (MT3)
- Chuck Size: ~1-3/16 in

Dimensions & Weight:
- Length: ~7 in
- Width: ~7.1 in
- Height: ~19 in
- Weight: ~23–25 lb

Construction:
- Metal housing (heavy-duty)
- Dual-mount gear case

Features:
- Reverse function (ideal for tapping)
- Dual-mount / reverse mount design for tight-space drilling
- High drill pressure capability for thick steel
- Designed for production and industrial use
- Fast bit changes with Morse taper system

Usage:
- Structural steel drilling
- Bridge and industrial fabrication
- Heavy plate drilling
- Thread tapping operations
